Adventurer Li- 30A PWM Flush Mount Charge Controller w/ LCD Display

Adventurer Li- 30A PWM Flush Mount Charge Controller w/ LCD Display
SKU: RNG-CTRL-ADV30-LI

$69.99 $59.99
Bluetooth Module *

Availability:

Renogy's fulfillment center will remain open to ensure that you are equipped with the reliable energy solution. Please note that due to an increase in order volume, there may be a slight delay. Thank you!



Description

The new and improved Renogy Adventurer-Li adds two great features. The first is Lithium battery charging capability. The programmable Lithium charging voltage allows the Adventurer-Li to charge most Lithium batteries on the market. The second is the RS232 port that is used to communicate with the new Renogy BT-1 Bluetooth module. The Bluetooth module will be used to pair the Adventurer-Li with the upcoming Renogy APP. The Renogy Adventurer-Li is a 30A PWM solar power charge controller that is designed to be used with 12V or 24V photovoltaic systems. This advanced negative-ground controller is designed for aesthetically clean flush mounting on RV or camper walls, however if flush mounting does not appeal to you, the included Adventurer-Li Surface Mount Attachment give you the option to forget it. Integrating highly efficient PWM charging, the Adventurer-Li increases battery longevity by regulating the charge flowing from the solar panels to the battery bank. It features an LCD screen for displaying system operation information and data, and allows for full control of parameter settings. This charge controller comes equipped with a fully comprehensive self-diagnostic system and electronic protection functions to prevent damage from installation mistakes or system faults.

If you have any questions regarding this product, please call us at 1 (909) 287-7111 or email support@renogy.com.

Key Features

Unique
  • Unique USB port on the front display
  • The only Renogy controller with flush mount capabilities.
  • RS232 port allows communication with BT-1 Bluetooth module and usage of Renogy BT smartphone app
Safe
  • Negative-ground controller
  • Protection against: overcharging, overload, short-circuit, and reverse polarity
  • 4 Stage PWM charging (Bulk, Boost, Float, and Equalization) prevents batteries from over-charging and over-discharging
Smart
  • 12V and 24v compatibility
  • LCD screen for displaying operating information and data
  • Compensates for temperature, automatically corrects charging and discharging parameters, and improves battery longevity
Versatile
  • Compatible with Sealed, Gel, Flooded and Lithium batteries
  • The included Adventurer Surface Mount allows for versatility in mounting


Package Includes

Renogy Adventurer Li 30A PWM Charge Controller

1 x

Renogy Adventurer Box

Renogy Wanderer 30A PWM Charge Controller

1 x

Options: BT-1 Bluetooth Module

BT-1 Bluetooth Module

1 x




Renogy 30A PWM Flush Mount Charge Controller
Nominal Voltage: 12 VDC/ 24 VDC USB Output: 5V, 2.4A Max
Rated Charge Current: 30A Max. PV Input Voltage: 50 VDC
Equalization Voltage: Sealed: 14.6 V; Gel: None; Flooded: 14.8 V Boost Voltage: Sealed: 14.4 V; Gel: 14.2 V; Flooded: 14.6 V; Lithium: 14.2 V
Float Voltage: 13.8 V Max. PV Input Power: 12V(400W) / 24V(800W)
Self-consumption: ≤13mA Temperature Compensation Coefficient: -3mV/°C/2V
Operating Temperature: -13°F to 131°F Storage Temperature: -31°F to 176°F
Enclosure: IP20 Dimensions: 6.56 x 4.50 x 1.90 inches
Terminals: Up to 8 AWG Weight: 0.6 lbs
Options: BT-1 Bluetooth Module
Communication Protocol: RS232 Port Type: RJ12
Input Voltage: 5V Protection Grade: IP54
Standby Power Consumption: 0.04W Operating Power Consumption: 0.05W
Communication Range: ≤82ft Serial Baud Rate: Fixed Baud Rate 9600bps
Cable Length: 5.00 m (16.4 ft) Dimensions: 2.65 X 1.38 X 0.55 in (67.3 X 35 X 14 mm)
Installation Dimensions: 67.3 φ3.5mmï¼?.66 φ 0.14inï¼?/td> Operation Temperature: -20℃~85℃(-4°F to 185°Fï¼?/td>
Weight: 130g (4.58oz)


Warranty Information

Accessories 2-year material warranty


Certification




Please click the links below to download Manual:
Renogy BT-1 Bluetooth Module
Renogy BT App for solar charge controller
