The Phoenix Powerbox

20W All-in-one Solar Kit

The Phoenix Generator is an all-in-one unit that will give you a complete solar charging system in the size of a briefcase. Ideal for smaller electronics and great for camping, weekend trips, emergencies, or anywhere power is needed.

Learn More
All-in-One
Solar System
The capability to add up to 100 watts more
Rechargeable with AC, Solar, and a 12V car charging socket
Multi-mode 3W LED Light

Description

With the rest of your life being as mobile as it is, it doesn't make sense that your power source shouldn't be too. With the Phoenix Portable Solar Generator, you won't have to compromise your power needs just to spend some time in the great outdoors! Enjoy the best of both worlds with power made portable by Renogy. The Phoenix is an all-in-one portable solar power system specifically designed for mobile, off-grid applications and is ideal for emergencies. This compact, lightweight backup generator combines two highly efficient Renogy 10W Monocrystalline Solar Panels and can expand up to 120 watts with additional PVs. The Phoenix can be charged by solar, AC power, or car power.
The Phoenix is ideal for powering several on-the-go appliances during a weekend trip, or to keep for back-up power in case of an emergency. The Phoenix is an all-in-one portable solar power system specifically designed for mobile, off-grid applications, and is ideal for emergencies. This compact, lightweight back-up system combines two highly efficient Renogy 10W Monocrystalline Solar Panels and is capable of expanding up to 120 watts. The Phoenix is ideal for powering several on-the-go appliances during a weekend trip, or even in an emergency situation.

If you have any questions regarding this product or any other solar mounting component, please give us a call at 1 (800) 330-8678 or email sales@renogy.com

Specifications

DC CHARGER PHOENIX SPECIFICATIONS
DC Input:SOLAR, CIG Charging Temperature Range 0~45C°
DC PV Input Voltage Range:17-30VDC Operation Temperature Range -20~60C°
DC Max Additional (Renogy) Panel:100W Cooling:Fan + Convection
Max Cigarette Socket Input DC Current:3A Industrial Design Material:ABS + PC + Aluminum
  Dimensions: 16.14 x 13.77 x 3.89 inches
  Weight:12.78 lbs
AC OUT: INVERTER BATTERY
Output Wave Form:Pure Sine Wave Battery Type:Li-ion Battery Pack
Total Harmonic Distortion (THD):10% Battery Standard Voltage:14.8V
Output AC Voltage:110 vac Battery Capacity:16Ah
Output AC Frequency:60 Hz Battery Max Charging Current:9A
Min Inverter Efficiency :80% Battery Cycle Life:1500
Max Continuous Output Power:150 w
Overload Protection:170W Max
Over Temperature Protection:YES
Short Protection:Yes
Low Voltage Protection:Yes
DC OUT SAFETY STANDARDS
DC Output:2 x 12V@3A max (6A Total) FCC:Yes
USB Output:4 x 5V@2.4A max (6A Total) UN 38.3 Standard:Yes
Cigarette Socket:12V 12.5A


Warranty Information


Panels

25-year power output warranty: 5 year/95% efficiency rate, 10 year/90% efficiency rate, 25-year/80% efficiency rate

5-year material and workmanship warranty

Accessories 1-year material warranty


Certification

What's is included?

The Renogy Phoenix - 20W All-in-One Solar Kit



Small Tilt Mount For Renogy 10W/20W/30W Solar Panels

1 x

Renogy CIG to DC Adaptor Cord

20A OR 40A MPPT Charge Controller

1 x

Renogy 5.5mm DC to Light Bulb Socket

Mounting Z Brackets

1 x

Renogy MC4 to DC Adaptor Cord

20A OR 40A MPPT Charge Controller

1 x

Renogy AC Power Adaptor Cord

Mounting Z Brackets

1 x

Warranty/Manual

Renogy Phoenix
